RIFI Electrical Metallic Tubing (EMT) is available in various sizes to accommodate different electrical wiring needs.
Electrical Metallic Tubing/EMT conduit/EMT tubing/EMT pipe
Finish: Pre-galvanized /Hot-Dipped Galvanized
Size: 1/2"-4" emt conduit
Brand Name: RIFI
Length : 10 feet/3.05m
Material : Carbon steel
Standard : UL797,CSAC22.2 NO.83.1 and ANSI C80.3
| Trade Size | Outside Diameter | Wall Thickness A | Wall Thickness B | Length | Packing | ||||
| inch | mm | inch | mm | inch | mm | feet | mm | Bundle | |
| 1/2" | 0.706 | 17.93 | 0.042 | 1.07 | 0.033 | 0.85 | 10 | 3050 | 20pcs |
| 3/4" | 0.922 | 23.42 | 0.049 | 1.25 | 0.039 | 1.00 | 10 | 3050 | 15pcs |
| 1" | 1.163 | 29.54 | 0.057 | 1.45 | 0.043 | 1.10 | 10 | 3050 | 10pcs |
| 1-1/4" | 1.510 | 38.35 | 0.065 | 1.65 | 0.051 | 1.30 | 10 | 3050 | 5pcs |
| 1-1/2" | 1.740 | 44.20 | 0.065 | 1.65 | 0.051 | 1.30 | 10 | 3050 | 5pcs |
| 2" | 2.197 | 55.80 | 0.065 | 1.65 | 0.055 | 1.4 | 10 | 3050 | 5pcs |
| 2-1/2" | 2.875 | 73.03 | 0.072 | 1.83 | * | * | 10 | 3050 | 1pcs |
| 3" | 3.500 | 88.90 | 0.072 | 1.83 | * | * | 10 | 3050 | 1pcs |
| 3-1/2" | 4.000 | 101.60 | 0.083 | 2.11 | * | * | 10 | 3050 | 1pcs |
| 4" | 4.500 | 114.30 | 0.083 | 2.11 | * | * | 10 | 3050 | 1pcs |
